S243W Wifi Infrared Sight Night Vision Rechargeable Four Handheld
Thermal Imaging
Parameter:
| Item | S242 | S243 |
| Detector | Type | Uncooled FPA |
| Pixel | 240×180 | 384×288 |
| NETD | <60mk@30℃ |
| Image | FOV | 15.6°*11.7°(±5%) | 24.9°*18.7°(±5%) |
| Focal length | 15mm |
| Frame rate | 50HZ |
| Focus | Fixed without heating, no focusing |
| Digital zoom | 1.0~4.0X continuous zoom |
| Spectral range | 8-14μm |
| Image transmission | With wifi real-time image transmission |
| Cross hair | yes |
| Photographing and video | yes |
| Hot pot tracking | yes |
| Laser indicator | yes |
| Display | Monitor | Color screen 720*540 |
| Polarity | Black hot, white hot, red hot and Pseudo-color |
| Diopter adjustment | Adjust by knob |
| Power | Battery | 18650 li-ion rechargeable |
| Working time | 5 hours continuous |
| Charging | Support USB charging and power bank |
| External power | DC5V/2A(type-c) |
| Environment | Operation temperature | -20℃- +50℃ |
| Storage temperature | -40℃- +60℃ |
| IP ratings | IP66 |
| Drop resistance | 1 M |
| Physical | Weight | <0.4Kg |
| Dimension | <230*70*70mm |
| Interface | Power interface | Type-C for external charging |
| Video output | PAL |
Features:
1. Easy to use - With only four buttons and an intuitive interface,
the S243W thermal imager is super easy to operate with one hand and
can even be mounted on a stand to free up your hands
2. Thermal Scope - 730 yards detection range and 384×288 thermal
resolution, 4x digital zoom and 4 different thermal palette options
for improved recognition
3. Thermal imager - 720×540 resolution display. Infrared camera
with Wi-Fi hotspot and 32GB card gives you live video feed, video
recording and snapshot capture
4. Rechargeable - Built-in lithium-ion battery, support 5 hours of
work. And can charge thermal goggles via USB-C via adapter or power
bank
5. Reliable Vision - Handheld thermal monoculars display people and
animals in 100% dim or harsh light by infrared. Perfect for
outdoor, exploration, surveillance, rescue, security, hunting,
hiking and more.
