TN430 Series Thermal Imaging Night Vision Binoculars For Outdoor
Product parameters
Model | TN430 | TN450 | TN630 | TN650 |
Detector |
Detector Type | 400×300 @17μm, VOx | 640×480@12μm, VOx |
Spectral | 8μm～14μm |
NETD | ≤50mk |
Lens |
Focal Length | 35mm/F1.2 | 50mm/F1.2 | 35mm/F1.2 | 50mm/F1.2 |
FOV | 11.1°×8.3° | 7.8°×5.8° | 12.5°×9.5° | 8.8°×6.6° |
Focusing | Manual Focus |
Display |
Screen | Full-color 0.39'OLED Screen ×2,1024×768 |
Eyepiece | Exit pupil distance 16.4mm, Adjustable diopter -4~＋2, Adjustable
interpupillary distance
between 60mm~70mm |
Magnification | 2.3X~9.2X | 3.2X~12.8X | 2.0X~16X | 2.8X~22.4X |
Imaging |
Frame Rate | 50Hz |
Digital Zoom | 1X~4X (Smooth zoom) | 1X~8X (Smooth zoom) |
Color Palettes | White Hot, Black Hot, Customized red hot, Blue Hot, Red Hot, Green
hot |
Scenes Modes | Enhanced, Highlight, Natural |
Picture-in-picture | Picture-in-picture enlarged image is displayed on the upper left,
upper middle or upper right |
Functions |
Photo | √ | √ | √ | √ |
Video | √ | √ | √ | √ |
Hotspot Tracking | √ | √ | √ | √ |
Laser Designating | Red Yellow Green |
Laser Ranging | Single ranging or continuous ranging |
Wi-Fi/APP | Wi-Fi share photo and video, also can controlled by app(IOS &
Android) |
Compensation Modes | Auto Compensation / Shutter Compensation / Scene Compensation |
Other | Smooth Magnification,Image Enhancement, Brightness and contrast of
image are adjustable,GPS,Compass,Gyroscope,Bluetooth, etc |
Power Supply |
Battery Type | Removable Standard 18650 Li-ion battery x2 |
Working Time | ≥6h |
Interface |
USB | TYPE C (USB 2.0 standard ) for charging, Data tranmission |
Video Output | Micro HDMI |
Tripod Interface | Inch 1/4-20 |
Memory Card | Built-in 16GB SD card,Max. support 128G |
Environmental Characteristics |
Operating Temperature | -10°C～50°C |
Storage Temperature | -30°C～60°C |
Encapsulation | IP66,1-meter drop test |
Certificate | UN38.3 (Battery certificate), RoHS, CE, FCC, EAC |
Weight & Dimensions |
Weight | 860g | 880g | 860g | 880g |
Dimensions | 162mm×146mm×70mm |
Package Contents |
Standard | Power adapter,Type-C USB cable,Micro HDMI cable,Lens cover,Wrist
strap, Removable shading eye blinders x2,Portable package,Quick
Start Guide |
Optional | Hand shank,Picatinny rail |
Detection Range |
Human:1.8m×0.5m | 1000m | 1000m | 1400m | 2000m |
Vehicle:2.3m×2.3m | 2400m | 2400m | 3000m | 3300m |
Recognition Range |
Human:1.8m×0.5m | 500m | 500m | 700m | 1000m |
Vehicle:2.3m×2.3m | 1000m | 1000m | 1400m | 2000m |
Main Features
> IR resolution up to 640 × 480, Superior image quality
> Quick location, laser ranger finder with 600m accuracy
> Full color OLED 1024×768 high-definition display, easy
observation
> Adjustable interpupillary distance between 60mm~70mm
> Well-designed PIP mode, highlighting the target
> Realize live image and remote control via WIFI connection
Application:
> Night hunting
> Law enforcement
> Search & Rescue
> Personal security
Instruction
TN Normae Series follows classic binocular design, greatly reducing
the fatigue feeling of long-time observation.
It adopts high-sensitivity VOx uncooled IR detector, bring you high
quality imaging and immersive observation experience
with full color OLED 1024×768 high-definition display. A variety of
functions to meet all your needs, such as taking photos, videos,
WIFI, laser ranging, GPS, compass, etc.
