TR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal Length

Ask Lasest Price
Brand Name :	OEM, ODM All Available
Certification :	CE,FC,RoHS
Delivery Time :	3~7
Payment Terms :	T/T. L/C, Western Union, Money Gram
Supply Ability :	30000PCS/Month
Model Number :	TR20-25mm

Add to Cart

Product Details
Company Profile

TR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal Length

TR20 Thermal Imaging Gun Sight, 384* 288 Ir Resolution And 35mm Focal Length

Parameter:

TR20	25mmm
Resolution,Pixel	384×288
Refresh Rate	50Hz
Pixel Size, micron	12μm
Objective Lens	25mm/f1.0
Magnification	2.04 - 8.16 x
Digital zoom	2x,4x
Eyerelief	40mm
Field of View (HxV)	10.5 x 7.9
Dioptre adjustment, dpt	± 5
Reticle Type	8-Pattern optional, or “NO reticle”
Reticle Color	4 colors: White, Black, Red and blue
Image Palettes	White Hot / Black Hot/ red hot /green hot/ Iron red / Sky
Display Resolution	1280x960
Laser locator	1mw red dot CAL
Detection distance Human(1.8×0.5)m	1000
Detection distance Vehicle(2.3×2.3)m	2500
Recognition distance Human(1.8×0.5)m	500
Recognition distance Vehicle(2.3×2.3)m	1000
Battery Type	Li-ion 18650 Rechargeable Battery Replaceable
Battery Life (Operating)	5 hours
External power supply	USB type c
Protection rate	IP66
Operating Temperature	-30℃ ... +60 ℃
Storage Temperature	-50℃.. +70 ℃
Size (L × W × H),mm / inch	188.8mm51mm74.1mm
Weight (W/o battery),Kg/ oz	560g
Housing Materials	Aluminum Alloy

Features:

1.Light weight,Compact size,Powerful functions
2.Rugged with high Shock Resistance
3.12um thermal imaging sensor, Ultra clear image quality
4.Mobile with Wifi connection for remote control
5. Expandable Laser Rangfinder (optional)
