Military Infrared Thermal Imaging Cooling With GPS, Electronic Compass, Laser Ranging

Ask Lasest Price
Brand Name :	OEM, ODM All Available
Certification :	CE,FC,RoHS
Delivery Time :	3~7
Payment Terms :	T/T. L/C, Western Union, Money Gram
Supply Ability :	30000PCS/Month
Model Number :	C3320

Add to Cart

Product Details
Company Profile

Military Infrared Thermal Imaging Cooling With GPS, Electronic Compass, Laser Ranging

Military Infrared Thermal Imaging Cooling With GPS, Electronic Compass, Laser Ranging

Parameter:

Specification of cooled thermal imaging binocular
Sensor type	cooled FPA
Resolution	320*256
Wavelength	3-5μm
Pixel pitch	30μm
NETD	25MK./@25℃
MRTD	≤0.18K
Frame rate	50HZ
Cool down type	<6min
Lens	f=20-200mm F#4.0
Focus	Auto/manual
FOV	2.75°x2.2°~18.3°x14.7°
Electronic zoom	1x~4x
Image control	White/black polarity;auto,manual gain,
Day/Night imaging
Sensor type	1/2' Low luminance camera
Resolution	720TVL
Frame rate	25HZ
Lens	f=50mm
Focus	f=50mm
Working luminance	0.001lux
Display
Display type	OLED
Resolution	1024x768
Reticles luminance	Customized
GPS
GPS	GPS,SNMS
GPS accuracy	≤10m.
Target geolocation	opitions
DMC
Type	Digital Compass
Accuracy	≤1°(Heading)
LRF
Type	1.54μm
Eye safe	Eye safe Class1
Min.distance	100m
Max.distance	5Km(atmosphere visibility>3.5km)
Accuracy	≤2m
Frequency	20ppm
System
Standby	Yes
Video out	BNC PAL
Recoding memory	32G
Working temp.	-30℃/55℃
Waterproof	IP67
Drop test	1.5m
interface	USB2.0
Power	+12v~+16v
Working time/cycle	4h(20℃)
Battery type	Li-ion
External power	+24v
Tripod connection	1/4‘
Included cables	Batteries,1charger,AC/DC adaptor,connection cable,hard case

Features:

1.High resolution thermal imager,high resolution visual camera,work all day,see through glare;

2.GPS,electrical compass,eye-safe laser range finder

3.The output imager can be displayed on its color OLED display and alternatively on a control&display units connected to a host machine which makes it suitable for comples maneuvers
